Determination of Compressive Strength of Cylindrical Concrete Specimens

 Experiment No: 14

Determination of Compressive Strength of Cylindrical Concrete Specimens




Introduction



The measure of compressive strength is the most frequently performed test on hardened concrete. The compressive strength is a fundamental structural design criterion that guarantees the ability of the structure to withstand the designed load. Consistently, the compressive strength increases as the water-cement ratio decreases. With a direct correlation between the water-cement ratio and concrete quality, compressive strength is frequently used as an indicator of quality, including longevity and resistance to deformation caused by weathering. Hence, designers often require a substantial compressive strength of the concrete to guarantee superior quality, even if this strength is not necessary for providing structural support. The compressive strength f′c of normal-weight concrete ranges from 20 to 40 megapascals (3000 and 6000 pounds per square inch).



Factors Affecting Compressive Strength of Concrete:

·        Water-Cement Ratio

·        Air entrainment

·        Cement type

·        Aggregate type

·        Mixing water

·        Admixtures

·        Curing conditions

·        Compaction and Workmanship

·        Age of Concrete

·        Mix Design

Scope

This test method covers determination of compressive strength of cylindrical concrete specimens. The results from this test are primarily used to determine whether the concrete mixture meets the specified strength requirements for structural applications.



Purpose



To determine the compressive strength of cylindrical PCC specimens, such as molded cylinders.



ASTM Designation



ASTM C39—Compressive Strength of Cylindrical Concrete Specimens.



Terminology



hydraulic cement

a cement that sets and hardens by chemical reaction with water and is capable of doing so under water.

Portland cement

a hydraulic cement produced by pulverizing clinker, consisting essentially of crystalline hydraulic calcium silicates, and usually containing one or more of the following: water, calcium sulfate, up to 5 % limestone, and processing additions.

Workability –

 Workability of concrete is defined in ASTM C-125 as the property determining the effort required to manipulate a freshly mixed quantity of concrete with minimum loss of homogeneity. The term manipulate includes the early-age operations of placing, compacting, and finishing. The effort required to place a concrete mixture is determined largely by the overall work needed to initiate and maintain flow, which depends on the rheological property of the lubricant (the cement paste) and the internal friction between the aggregate particles on the one hand, and the external friction between the concrete and the surface of the formwork on the other.

water-cement ratio —

the ratio of the mass of water, exclusive only of that absorbed by the aggregates, to the mass of portland cement in concrete, mortar, or grout, stated as a decimal.

Concrete —

a composite material that consists essentially of a binding medium within which are embedded particles or fragments of aggregate; in hydraulic-cement concrete, the binder is formed from a mixture of hydraulic cement and water.

concrete, fresh

concrete that possesses enough of its original workability so that it can be placed and consolidated by the intended methods.

concrete, hardened

concrete that has developed sufficient strength to serve some defined purpose or resist a stipulated loading without failure.

Consistency — (fresh cementitious mixture)

 the relative mobility or ability to flow.

Curing

action taken to maintain moisture and temperature conditions in a freshly-placed cementitious mixture to allow hydraulic cement hydration and (if applicable) pozzolanic reactions to occur so that the potential properties of the mixture may develop.

Pozzolan —

a siliceous or siliceous and aluminous material, which in itself possesses little or no cementitious value but will, in finely divided form and in the presence of moisture, chemically react with calcium hydroxide at ordinary temperatures to form compounds possessing cementitious properties.

cementitious material (hydraulic)

an inorganic material or a mixture of inorganic materials that sets and develops strength by chemical reaction with water by formation of hydrates and is capable of doing so under water.

Fracture:

The failure of the specimen under compression load.

Significance and Use

Good judgment is necessary when interpreting the importance of compressive strength measurements obtained by this test technique, as strength is not an inherent or essential characteristic of concrete composed of specific elements. The values obtained will be influenced by several factors, including the dimensions and form of the specimen, the processes of batching and mixing, the techniques of sampling, molding, and fabrication, as well as the age, temperature, and moisture conditions throughout the curing process. The outcomes of this testing method serve as a foundation for quality control of concrete proportioning, mixing, and placing operations; assessment of conformity to technical requirements; evaluation of the effectiveness of admixtures; and other related applications.

The compressive strength of concrete is a critical measure of the material's ability to withstand axial loads. It is used for:

·         Quality Control: Verifying that concrete delivered to a project meets specified strength requirements.

·         Structural Design: Providing engineers with essential data to ensure that a concrete structure can safely bear loads.

·         Material Evaluation: Comparing different concrete mixtures for their relative strengths.

·         Compliance: Meeting regulatory and construction codes, ensuring that the materials used in construction align with project specifications.

Apparatus

Testing Machine:

The testing machine shall be of a type having sufficient capacity and capable of providing the required rates of loading.

Bearing Blocks:

The upper and lower bearing blocks.

The dimensions of the bearing face of the upper bearing block shall not exceed the following values:

Nominal Diameter of Specimen, mm [in.]

Maximum Diameter of Round Bearing Face, mm [in.]

Maximum Dimensions of Square Bearing Face, mm [in.]

50 [2]

105 [4]

105 by 105 [4 by 4]

75 [3]

130 [5]

130 by 130 [5 by 5]

100 [4]

165 [6.5]

165 by 165 [6.5 by 6.5]

150 [6]

255 [10]

255 by 255 [10 by 10]

200 [8]

280 [11]

280 by 280 [11 by 11]



The lower bearing block shall be at least 25 mm [1.0 in.] thick when new, and at least 22.5 mm [0.9 in.] thick after resurfacing.



Load Indication:

The testing machine shall be equipped with either a dial or digital load indicator.

Specimens:

·        Specimens will not undergo testing if any individual diameter of a cylinder deviates from any other diameter of the same cylinder by an amount exceeding 2%.

·        Prior to testing, test specimens must not exceed a deviation of 0.5° from perpendicularity to the axis, which is equivalent to 1 mm in 100 mm [0.12 in. in 12 in.].

·        Compression test specimens that are not level within a range of 0.050 mm must undergo sawing, grinding, or capping as detailed in Practice ASTM C617/ASTM C617M or, if allowed, Practice ASTM C1231/ASTM C1231M.

·        The cross-sectional area of the test specimen must be measured to the closest 0.25 mm [0.01 in.] by averaging two diameters measured at right angles to each other at approximately mid height of the specimen.

·        Wipe off any excess moisture from the surface using a towel and determine the mass of the specimen.

·        When density determination is not necessary and the length to diameter ratio is less than 1.8 or more than 2.2, measure the length of the specimen to the nearest 0.05 D.



Procedure

·        Once moist-cured specimens have been removed from moist storage, compression tests should be conducted as soon as possible. The test specimens must be maintained moist using any appropriate method throughout the time between their removal from moist storage and conducting testing. Their compressive test shall be tested in moist conditions.

·        Tolerances for specimen ages are specified below:

Test Age

Permissible Tolerance

24 h

±0.5 h

3 days

±2 h

7 days

±6 h

28 days

±20 h

90 days

±2 days



·               Placing the Specimen:

 Place the lower bearing block on the testing machine's table or platen, wiping clean the bearing faces of upper and lower blocks, spacers if used, and specimen. If using unbonded caps, wipe clean the retainer surfaces and center them on the specimen. Place the specimen on the lower bearing block and align its axis with the upper bearing block's center of thrust.

·        Zero Verification and Block Seating:

Before testing a specimen, ensure the load indicator is set to zero and adjust it if necessary. After placing the specimen in the machine, gently tilt the movable block to ensure the bearing face is parallel to the top of the test specimen before applying the load.

·        Rate of Loading:

Apply the load continuously and without shock. For screw-type machines, use a rate of loading of 1 mm/min (0.05 in./min). For hydraulically operated machines, apply the load at a constant rate within the range of 0.15 to 0.35 MPa/s (20 psi/sec to 50 psi/sec). During the first half of the anticipated loading phase, a higher rate of loading is permitted. No adjustment in the control of the testing machine should be made while the specimen is yielding rapidly, immediately before failure.



·     Apply the load until the specimen fails, and record the maximum load carried by the specimen during the test. Note the type of failure and the appearance of the concrete.



Calculation

·        The compressive strength of a specimen can be determined by dividing its maximum load carried by the specimen during testing by its average cross-sectional area.

·        If the specimen length to diameter ratio is less than 1.8, correct the obtained result by multiplying the appropriate correction factor as shown in the table.

L/D

Factor

1.75

0.98

1.50

0.96

1.25

0.93

1.0

0.87



·         Note: The correction factors are applicable to lightweight concrete weighing between 100 and 120 lb/ft3 and normal weight concrete, and are applicable to concrete dry or soaked at loading time. They are also applicable to nominal concrete strengths from 2000 to 6000 psi [15 to 45 MPa]. Values not given in the table shall be calculated by interpolation.

Report:

1.     Identification number

2.     Diameter (and length, if outside the range of 1.8D to 2.2D)

3.     Cross-sectional area

4.     Maximum load

5.     Compressive strength calculated to the nearest 10 psi [0.1 MPa]

6.     Type of fracture, if other than the usual cone (Fig. 1)

7.     Defects in either specimen or caps, and,

8.     Age of specimen


Fig.1: Typical fracture pattern of concrete cylinders: (1) cones (2) cone and vertical cracks (3) vertical cracks (4) shear (5) side fracture (6) side fractures with pointed ends (7) cone and shear

Lab Questions:

Fundamental Questions:

1.      What is compressive strength, and why is it important in concrete?

2.      How does compressive strength relate to the overall performance of concrete in structures?

3.      What are cylindrical concrete specimens, and why are they used for compressive strength testing?

4.      What is the standard size of cylindrical concrete specimens used for compressive strength testing?

5.      Why are specific sizes (e.g., 150 mm x 300 mm or 100 mm x 200 mm) used?

6.      Why is compressive strength measured at specific intervals such as 7 days and 28 days?

7.      What is the significance of these curing periods?

Procedure-Related Questions:

8.      Can you describe the procedure for testing the compressive strength of cylindrical concrete specimens?

9.      How is the load applied to the concrete cylinder during the test?

10.  What is the rate of loading, and why is it important?

11.  What is the purpose of capping or grinding the ends of the concrete cylinder before testing?

12.  How does this affect the accuracy of the test?

13.  How do you calculate the compressive strength of a cylindrical concrete specimen?

14.  What is the formula used for calculating compressive strength from the test results?

15.  Why is it important to ensure that the axis of the specimen is aligned with the axis of the loading machine?

16.  What are the key steps in preparing and curing the concrete specimens before testing for compressive strength?

Interpretation and Results:

17.  What is a typical range of compressive strength for normal concrete?

18.  How does high-strength concrete differ in terms of compressive strength?

19.  How do you interpret the test results if the concrete cylinder fails prematurely or at a lower strength than expected?

20.  What could cause low compressive strength in a concrete specimen?

21.  How do curing conditions affect the compressive strength of concrete?

22.  What are the reasons for observing cracks before reaching the ultimate load during compressive testing?

23.  What is the significance of the modulus of elasticity in relation to compressive strength testing?

24.  How does it affect the behavior of concrete under load?

Factors Affecting Compressive Strength:

25.  What factors influence the compressive strength of concrete specimens?

26.  How do water-cement ratio, aggregate size, and mix design impact strength?

27.  How does the temperature and environment during curing affect the compressive strength of concrete?

28.  What is the impact of air entrainment on compressive strength?

29.  How does improper compaction of the concrete mix influence the compressive strength?

30.  What could cause variability in the results when testing different cylinders from the same batch of concrete?

Equipment and Safety:

31.  What equipment is used for testing the compressive strength of concrete cylinders?

32.  What is the role of the universal testing machine (UTM) in this process?

33.  What are the safety precautions that should be followed while performing the compressive strength test?

34.  Why is it important to regularly calibrate the testing machine used for compressive strength testing?

35.  How do you ensure that the testing machine is applying the load uniformly across the surface of the specimen?

Standards and Quality Control:

36.  Which standard or code is followed for determining the compressive strength of cylindrical concrete specimens?

37.  Can you explain the key requirements of ASTM C39 for this test?

38.  What is the significance of quality control when preparing and testing concrete cylinders for compressive strength?

39.  What are the limitations of the compressive strength test on cylindrical specimens?

40.  How do you compare the results of compressive strength from lab-cured specimens versus field-cured specimens?
